Union Male Threaded x SW
OEM/ODM Service
BAFAW provides end-to-end support for your pipeline projects, delivering a true one-stop OEM/ODM solution that efficiently and reliably fulfills your custom requirements.
Compliance with Standards
All BAFAW’s products comply with international standards such as ASME, ANSI, DIN, and ISO. We provide comprehensive material and inspection reports to ensure worry-free project audits and safe usage.
Large or Small Order
BAFAW delivers with the same professionalism whether you need bulk production or just a few samples. Our flexible model supports rapid sampling across categories and stable large-scale customization.
Introduction
| Nom. Pipe Size | A (Min) | B1 | B | D | K (Min) | L |
|---|---|---|---|---|---|---|
| 1/4″ | 21.8 | 13.7 | 14.61 | 10.01 | 9.7 | 55.4 |
| 3/8″ | 25.9 | 17.1 | 18.03 | 13.28 | 9.7 | 60 |
| 1/2″ | 31.2 | 21.3 | 17.53 | 11.76 | 9.7 | 68 |
| 3/4″ | 37.1 | 26.7 | 21.72 | 15.04 | 12.7 | 75.9 |
| 1″ | 45.5 | 33.4 | 27.05 | 20.17 | 12.7 | 86 |
| 1-1/4″ | 54.9 | 42.2 | 33.78 | 25.88 | 12.7 | 95.1 |
| 1-1/2″ | 61.5 | 48.3 | 43.05 | 28.84 | 12.7 | 100.5 |
| 2″ | 75.2 | 60.3 | 61.62 | 40.13 | 15.7 | 112.1 |
(1) Dimensions refer to MSS SP-83 TABLE 5.
